S355J2/S355K2/S355NL/S355J0/執(zhí)行標準/EN10025力學特性(Mechnical property) | |||||||||||||
牌號 Grade | 不同厚度[mm]下的 *小屈服強度Min ReH[MPa] under various thickness | 不同厚度[mm]下的 拉伸強度Min Tensile Rm [MPa] | |||||||||||
≤16 | ＞16 ≤40 | ＞40 ≤63 | ＞63 ≤80 | ＞80 ≤100 | ＞100 ≤150 | ＞150 ≤200 | ＞200 ≤250 | ＞250 ≤400 | 3 ≤100 | ＞100 ≤150 | ＞150 ≤250 | ＞250 ≤400 | |
S235JR | 235 | 225 | 215 | 215 | 215 | 195 | 185 | 175 | - | 360-510 | 350-500 | 340-490 | - |
S235J0 | - | - | |||||||||||
S235J2 | 165 | 330-480 | |||||||||||
S275JR | 275 | 265 | 255 | 245 | 235 | 225 | 215 | 205 | - | 410-560 | 400-540 | 380-540 | - |
S275J0 | - | - | |||||||||||
S275J2 | 195 | 380-540 | |||||||||||
S355JR | 355 | 345 | 335 | 325 | 315 | 295 | 285 | 275 | - | 470-630 | 450-600 | 450-600 | - |
S355J0 | - | - | |||||||||||
S355J2 | 265 | 450-600 | |||||||||||
S355K2 | 265 | 450-600 | |||||||||||
